Pbfree Code

 No

Rohs Code

 No

Part Life Cycle Code

Obsolete

Part Package Code

SOJ

Package Description

0.300 Inch, Plastic, Soj-26/20

Pin Count

20

Reach Compliance Code

Unknown

ECCN Code

EAR99

HTS Code

8542.32.00.02

Access Mode

Fast Page

Access Time-Max

70 Ns

Additional Feature

Ras Only; Cas Before Ras; Hidden Refresh

I/O Type

Common

JESD-30 Code

R-PDSO-J20

JESD-609 Code

e0

Length

17.145 Mm

Memory Density

4194304 Bit

Memory IC Type

Fast Page Dram

Memory Width

4

Number of Functions

1

Number of Ports

1

Number of Terminals

20

Number of Words

1048576 Words

Number of Words Code

1000000

Operating Mode

Asynchronous

Operating Temperature-Max

70 °C

Operating Temperature-Min

Organization

1mx4

Output Characteristics

3-State

Package Body Material

Plastic/Epoxy

Package Code

SOJ

Package Equivalence Code

SOJ20/26,.34

Package Shape

Rectangular

Package Style

Small Outline

Qualification Status

Not Qualified

Refresh Cycles

1024

Seated Height-Max

3.68 Mm

Self Refresh

No

Standby Current-Max

0.001 A

Supply Current-Max

0.08 Ma

Supply Voltage-Max (Vsup)

5.5 V

Supply Voltage-Min (Vsup)

4.5 V

Supply Voltage-Nom (Vsup)

5 V

Surface Mount

Yes

Technology

Cmos

Temperature Grade

Commercial

Terminal Finish

Tin Lead

Terminal Form

J Bend

Terminal Pitch

1.27 Mm

Terminal Position

Dual

Width

7.62 Mm
