Manufacturer:

Club 3D

Model:

Radeon 9600XT

Part number:

CGA-E966TVD

Based on:

ATI Radeon 9600

Target market segment:

Desktop

Die name:

RV350

Fabrication process:

130 nm

Transistors:

76 million

Bus interface:

AGP 8x

Frequency

Graphics clock:

400 MHz

Memory specifications

Memory size:

256 MB

Memory type:

DDR

Memory clock:

200 MHz

Memory clock (effective):

400 MHz

Memory interface width:

128-bit

Memory bandwidth:

6.4 GB/s

Cores / Texture

Color ROPs:

4

Pixel shader processors:

4

Vertex shader processors:

2

Texture units:

4

RAMDACs:

400 MHz

Electric characteristics

Maximum power draw:

12 Watt

Video features

Multi-monitor:

Up to 2 displays

Maximum VGA resolution:

2048 x 1536

Performance

Pixel fill rate:

1.6 Gigapixels/s

Texture fill rate:

1.6 Gigatexels/s

Polygon throughput:

215 million polygons/sec

External connectors

Standard display connectors:

DVI-I S-Video VGA

Dimensions

Width:

Single-Slot

Other features / Support

OpenGL support:

2.0

DirectX support:

9.0

Pixel shader model:

2.0

Vertex shader model:

2.0
