Manufacturer:

ASUS

Model:

A9600XT

Part number:

A9600XT/TVD/128M

Based on:

ATI Radeon 9600XT

Target market segment:

Desktop

Die name:

RV360

Fabrication process:

130 nm

Transistors:

76 million

Bus interface:

AGP 8x

Frequency

Graphics clock:

500 MHz

Memory specifications

Memory size:

128 MB

Memory type:

DDR

Memory clock:

300 MHz

Memory clock (effective):

600 MHz

Memory interface width:

128-bit

Memory bandwidth:

9.6 GB/s

Cores / Texture

Color ROPs:

4

Pixel shader processors:

4

Vertex shader processors:

2

Texture units:

4

Textures/pixel:

16

RAMDACs:

400 MHz

Electric characteristics

Maximum power draw:

22 Watt

Video features

Multi-monitor:

Up to 2 displays

Maximum VGA resolution:

2048 x 1536

Performance

Pixel fill rate:

2 Gigapixels/s

Texture fill rate:

2 Gigatexels/s

External connectors

Standard display connectors:

DVI-I S-VHS/S-Video VGA

Dimensions

Width:

Single-Slot

Other features / Support

OpenGL support:

2.0

DirectX support:

9.0

Pixel shader model:

2.0

Vertex shader model:

2.0
