Manufacturer:

nVIDIA

Model:

Quadro4 750 XGL

Reference card?:

Yes

Target market segment:

Desktop Workstation

Die name:

NV25 GL

Fabrication process:

150 nm

Transistors:

63 million

Bus interface:

AGP 4x

Launch date:

February 2002

Frequency

Graphics clock:

275 MHz

Memory specifications

Memory size:

128 MB

Memory type:

DDR

Memory clock:

225 MHz

Memory clock (effective):

450 MHz

Memory interface width:

128-bit

Memory bandwidth:

7.2 GB/s

Cores / Texture

ROPs:

4

Pixel shader processors:

4

Vertex shader processors:

2

Texture units:

8

RAMDACs:

350 MHz

Video features

Maximum DVI resolution:

1600 x 1200

Maximum VGA resolution:

2048 x 1536

Performance

Pixel fill rate:

1.1 Gigapixels/s

Texture fill rate:

2.2 Gigatexels/s

Polygon throughput:

54 million triangles/s

External connectors

The number of analog outputs:

2

The number of digital outputs:

2

Standard display connectors:

2 x Single-Link DVI-I

Dimensions

Width:

Single Slot

Other features / Support

OpenGL support:

1.3

DirectX support:

8.1

Pixel shader model:

1.3

Vertex shader model:

1.1
